minio bin部署

使用bin方式部署minio服务集群。

Table of Contents

一、准备工作
二、部署 minio
三、部署 NGINX

一、准备工作

主机资源准备
确保有三台机器可用，每台机器的配置应满足 minio 的运行需求。例如：
主机名 IP 地址备注
node1 192.168.174.130 需要额外的数据盘
node2 192.168.174.131 需要额外的数据盘
node3 192.168.174.132 需要额外的数据盘
注意：集群版本的minio部署需要有单独的数据盘分区后进行挂载，才能作为driver的配置目录

主机名	IP 地址	备注
node1	192.168.174.130	需要额外的数据盘
node2	192.168.174.131	需要额外的数据盘
node3	192.168.174.132	需要额外的数据盘

设置免密登录

在三台机器上分别执行以下命令，生成 SSH 密钥并分发到其他机器：

 ssh-keygen
 ssh-copy-id root@192.168.174.130
 ssh-copy-id root@192.168.174.131
 ssh-copy-id root@192.168.174.132

关闭并且禁用防火墙自动启动

 systemctl stop firewalld
 systemctl disable firewalld

关闭selinux

 setenforce 0
 sed 's/SELINUX=enforcing/SELINUX=permissive/' -i /etc/selinux/config

二、部署 minio

下载 minio 二进制文件

在任意一台机器上下载 minio 的二进制文件，并分发到其他机器。例如：

 wget  https://dl.min.io/server/minio/release/linux-amd64/minio
 chmod +x minio
 mkdir -p /data/service/minio/{bin,conf,data/volume{1..2}}
 mv minio /data/service/minio/bin

将二进制文件分发到其他机器：

 ssh 192.168.174.131 "mkdir -p /data/service/minio/{bin,conf,data/volume{1..2}}"
 ssh 192.168.174.132 "mkdir -p /data/service/minio/{bin,conf,data/volume{1..2}}"
 scp /data/service/minio/bin/minio 192.168.174.131:/data/service/minio/bin
 scp /data/service/minio/bin/minio 192.168.174.132:/data/service/minio/bin

创建minio driver的挂载点

在每台机器上创建 mino的挂载点。以下是每台机器都要执行的操作：

以node1 (192.168.174.130)举例

 # 假设数据盘是nvme0n2，对其分两个区，每个占50%的大小
 parted  /dev/nvme0n2 -s  mklabel gpt mkpart data1 ext4 0% 50% mkpart data2 ext4 50% 100%
 # 格式化文件系统
 mkfs.xfs -f /dev/nvme0n2p1
 mkfs.xfs -f /dev/nvme0n2p2
 # 查看对应的UUID，并写入fstab
 ll /dev/disk/by-uuid/
 echo "UUID=<替换为nvme0n2p1对应UUID> /data/service/minio/data/volume1    xfs    defaults  0 0" >> /etc/fstab
 echo "UUID=<替换为nvme0n2p2对应UUID> /data/service/minio/data/volume2    xfs    defaults  0 0" >> /etc/fstab
 mount -a # 挂载磁盘
 lsblk # 查看确认挂载完毕

配置systemd启动相关文件

在每台机器上创建minio 的配置文件 minio.env。以下是单台机器的配置示例：

配置minio的启动配置文件

 cat > /data/service/minio/conf/minio.env << 'EOF'
 MINIO_VOLUMES="http://192.168.174.13{0...2}:9000/data/service/minio/data/volume{1...2}"
 MINIO_OPTS="--console-address :9001"
 MINIO_ROOT_USER=minioadmin
 MINIO_ROOT_PASSWORD=miniopass
 EOF

配置对应的systemd文件

 cat > /etc/systemd/system/minio.service << 'EOF'
 [Unit]
 Description=MinIO
 Documentation=https://min.io/docs/minio/linux/index.html
 Wants=network-online.target
 After=network-online.target
 AssertFileIsExecutable=/data/service/minio/bin/minio

 [Service]
 WorkingDirectory=/data/service/minio/
 ProtectProc=invisible
 EnvironmentFile=-/data/service/minio/conf/minio.env
 ExecStartPre=/bin/bash -c "if [ -z \"${MINIO_VOLUMES}\" ]; then echo \"Variable MINIO_VOLUMES not set in /data/service/minio/conf/minio.env\"; exit 1; fi"
 ExecStart=/data/service/minio/bin/minio server $MINIO_OPTS $MINIO_VOLUMES
 Type=notify
 User=root
 Group=root
 Restart=always
 LimitNOFILE=65536
 TasksMax=infinity
 TimeoutStopSec=infinity
 SendSIGKILL=no

 [Install]
 WantedBy=multi-user.target
 EOF

 systemctl daemon-reload
 systemctl restart minio
 systemctl enable minio

三、部署 NGINX

在nginx的服务器上部署nginx，配置后启动服务

 yum install nginx -y

 cat > /etc/nginx/conf.d/minio.conf << 'EOF'
 upstream minio_s3 {
 least_conn;
 server 192.168.174.130:9000;
 server 192.168.174.131:9000;
 server 192.168.174.132:9000;
 }

 upstream minio_console {
 least_conn;
 server 192.168.174.130:9001;
 server 192.168.174.131:9001;
 server 192.168.174.132:9001;
 }

 server {
 listen       9010;
 listen  [::]:9010;
 server_name  _;

 # Allow special characters in headers
 ignore_invalid_headers off;
 # Allow any size file to be uploaded.
 # Set to a value such as 1000m; to restrict file size to a specific value
 client_max_body_size 0;
 # Disable buffering
 proxy_buffering off;
 proxy_request_buffering off;

 location / {
     proxy_set_header Host $http_host;
     proxy_set_header X-Real-IP $remote_addr;
     proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
     proxy_set_header X-Forwarded-Proto $scheme;

     proxy_connect_timeout 300;
     # Default is HTTP/1, keepalive is only enabled in HTTP/1.1
     proxy_http_version 1.1;
     proxy_set_header Connection "";
     chunked_transfer_encoding off;

     proxy_pass  http://minio_s3; # This uses the upstream directive definition to load balance
 }
 }

 server {

 listen       9011;
 listen  [::]:9011;
 server_name  _;

 # Allow special characters in headers
 ignore_invalid_headers off;
 # Allow any size file to be uploaded.
 # Set to a value such as 1000m; to restrict file size to a specific value
 client_max_body_size 0;
 # Disable buffering
 proxy_buffering off;
 proxy_request_buffering off;

 location / {
     proxy_set_header Host $http_host;
     proxy_set_header X-Real-IP $remote_addr;
     proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
     proxy_set_header X-Forwarded-Proto $scheme;
     proxy_set_header X-NginX-Proxy true;

     # This is necessary to pass the correct IP to be hashed
     real_ip_header X-Real-IP;

     proxy_connect_timeout 300;

     # To support websocket
     proxy_http_version 1.1;
     proxy_set_header Upgrade $http_upgrade;
     proxy_set_header Connection "upgrade";

     chunked_transfer_encoding off;

     proxy_pass  http://minio_console/; # This uses the upstream directive definition to load balance
 }
 }
 EOF

 systemctl restart nginx
 systemctl status nginx

通过 http://<NGINX-IP:9011> 访问前端，可以访问即可，用户名密码为minioadmin/miniopass
